FUJI space THY-JXVF series hydraulic elevators are high-quality and reliable vertical transportation systems that are well-suited for both residential and commercial buildings.
Let's take a closer look at their features, advantages, application scenarios, and installation aspects.
Operating Principle: The FUJI space THY-JXVF series hydraulic elevators operate based on a hydraulic mechanism that uses liquid (hydraulic oil) to move the elevator cabin. This method enables high reliability and smooth operation.
Load-bearing Capacity: Depending on the model, these elevators can lift loads ranging from 320 to 7000 kg, making them versatile for various needs.
Lifting Height: The maximum lifting height varies from 5 to 15 meters, allowing for efficient service in multi - story buildings.
Lifting Speed: The average speed ranges from 0.25 to 1.0 m/s, ensuring comfortable and safe movement.
Dimensions: The FUJI space THY-JXVF series hydraulic elevators have cabins of various sizes, enabling adaptation to the specific requirements and space of your building.
Energy Efficiency: Hydraulic elevators are more efficient compared to traditional electro - mechanical elevators, significantly reducing electricity costs.
Low Noise Level: Operating much quieter than some other types of elevators, these systems provide a comfortable atmosphere in residential and commercial premises.
Safety: Modern FUJI space THY-JXVF series elevators are equipped with reliable safety systems, such as brakes, emergency systems, and manual control options, guaranteeing user protection.
Reliability and Durability: Manufactured from high-quality components, the FUJI space THY-JXVF series elevators perform excellently in operation and maintenance, ensuring a long service life.
The FUJI space THY-JXVF series hydraulic elevators can be installed in various types of buildings:
Residential Buildings: Ideal for private cottages, apartment buildings, and suburban complexes, they provide convenience for moving between floors not only for residents but also for cargo delivery.
Commercial Buildings: Used in stores, offices, and shopping centers, they facilitate the transportation of goods and materials.
Service Facilities: In hotels, restaurants, and medical institutions, hydraulic elevators ensure accessibility and comfort for all visitors, including those with limited mobility.
Installation Process: The installation of a hydraulic elevator requires a professional approach and can take from several days to several weeks, depending on the complexity of the project and the building's characteristics. The presence of a foundation for installing the hydraulic elevator must be considered.
Maintenance: To ensure the long - term operation of the FUJI space THY-JXVF series elevators, regular technical maintenance is recommended. This includes checking the hydraulic system, the oil pump, connecting elements, electrical components, and other key parts.
Emergency Procedures: The FUJI space THY-JXVF series elevators are equipped with many emergency control options, including an emergency communication system and evacuation capabilities, making them safe and reliable.
FUJI space THY-JXVF series hydraulic elevators are an excellent choice for anyone who wants to ensure convenient and safe movement between floors. Their modern technology, reliability, and numerous advantages make them a popular solution for suburban houses and commercial properties.
Model | Load Capacity (kg) | Min - Max Speed (m/s) | Standard Cabin Dimensions (W * D * H) | Door Dimensions (W * H) | Door Opening Type | Engine Model | Control Station Model |
THY-JXVF | 2000 | 0.5-1.0 | 2000×2500 | 1800×2100 | Sliding | GMV | JXW |
THY-JXVF | 3000 | 0.25-0.5 | 2200×3800 | 2000×2100 | Sliding | GMV | JXW |
THY-JXVF | 5000 | 0.25-0.5 | 2500×5500 | 2400×2100 | Sliding | GMV | JXW |
THY-JXVF | 7000 | 0.25-0.5 | 3000×6600 | 2800×2100 | Sliding | GMV | JXW |
Installation Process: The installation of a hydraulic elevator requires a professional approach and can take from several days to several weeks, depending on the complexity of the project and the building's characteristics. The presence of a foundation for installing the hydraulic elevator must be considered.
Maintenance: To ensure the long-term operation of the FUJI space THY-JXVF series elevators are equipped with many emergency control options, including an emergency communication system and evacuation capabilities, making them safe and reliable.
Residential Buildings: Ideal for private cottages, apartment buildings, and suburban complexes, they provide convenience for moving between floors not only for residents but also for cargo delivery.
Commercial Buildings: Used in stores, offices, and shopping centers, they facilitate the transportation of goods and materials.
Service Facilities: In hotels, restaurants, and medical institutions, hydraulic elevators ensure accessibility and comfort for all visitors, including those with limited mobility.
